| Vibration Input | ||
| Channels | 1 to 16 channels optional | Maximal 16-channel synchronous acquisition |
| Signal acquisition | Acceleration, velocity, displacement synchronously | - |
| Input impedance | 220K | - |
| Accelerometer max | 80g, 200mm/s, 10mm, 100mV/g sensor | - |
| Sensor drive current | 4mA@24V | Constant current supply for IEPE type |
| A/D conversion | 24bit delta-sigma ADC | - |
| Frequency range | 100Hz - 40kHz | - |
| Precision | 1% (0.1dB) | - |
| Rotating Speed & Process Information | ||
| Speed Channels | 2 channels, isolation input | TTL, Eddy current, Hall compatible |
| Process Channels | 4 channels, isolation input | ±12V or 4~20mA |
| Signal Processing & Basic Index | ||
| Window Type | Hanning, Rectangle window | - |
| Lines | Up to 12800 lines | - |
| Storage | 1G Bytes | - |
| Communication | RS232, RS485, CANbus, Ethernet | TCP/IP, 10/100baseT |
| IP Grade | IP65 | Dust and water resistant |
| Temperature | Working: (-40 - 70)ºC | Storage: (-50 - 85)ºC |
