| Vibration Input | ||
| Channels | 1 to 16 channels optional | Maximal 16-channel synchronous acquisition |
| Signal acquisition | Acceleration, velocity, displacement can be acquired synchronously | |
| Input impedance | 220K | |
| Accelerometer maximal value | 80g, 200mm/s, 10mm, 100mV/g sensor | |
| Sensor drive current | 4mA@24V | Constant current supply for IEPE type accelerometer |
| A/D conversion | 24bit delta-sigma ADC | |
| Frequency range | 100Hz - 40kHz | |
| Dynamic signal range | 110dB | |
| Precision | 1% (0.1dB) | |
| Rotating Speed | ||
| Channels | 2 speed channels, isolation input | |
| Compatible type | TTL, Eddy current, Hall | |
| Triggering level | 4V ~ 30Vpp | |
| Process Information & Output | ||
| Process Channels | 4 channels, isolation input | Signal range: ±12V or 4 ~ 20mA |
| Output Channels | 1 Channel | Type: SPST, Normally open or close |
| Signal Processing | ||
| Window | Hanning, Rectangle window | |
| Lines | 400 to 12800 | |
| Averaging | Linearity, peak hold | Times: 1, 2, 4, 8, 16, 32, 64 |
| Regular Index & Environment | ||
| Dimension & Weight | 300 x 400 x 167mm | 9.8Kg |
| IP Grade | IP65 | Working Temp: -40 to 70ºC |
| Power Supply | 100-240VAC or 24VDC | Consumption: < 20W |
