| Item No. | W (MM) | H (MM) | D (MM) | Rated Current (A) | Power Capacity (KVA) | GW (KG) | Motor (KW) |
|---|---|---|---|---|---|---|---|
| 1/3 Phase Input, 3 Phase Output 220V | |||||||
| FC100P-2S-0.4G | 89.60 | 197.20 | 139.00 | 6.5/2.1 | 0.7 | 1.30 | 0.4 |
| FC100P-2S-0.75GB | 89.60 | 197.20 | 139.00 | 8.2/4.0 | 1.5 | 1.30 | 0.75 |
| FC100P-2S-1.5GB | 89.60 | 197.20 | 139.00 | 14.0/7.0 | 3 | 1.30 | 1.5 |
| FC100P-2S-2.2GB | 89.60 | 197.20 | 139.00 | 23.0/9.6 | 4 | 1.30 | 2.2 |
| 3 Phase Input, 3 Phase Output 380V | |||||||
| FC100P-4T-0.75GB | 89.60 | 197.20 | 139.00 | 3.4/2.1 | 1.5 | 1.50 | 0.75 |
| FC100P-4T-5.5GB | 102.00 | 202.00 | 162.00 | 14.6/13.0 | 8.9 | 3.50 | 5.5 |
| FC100P-4T-11GB | 125.00 | 242.50 | 169.50 | 28.0/25.0 | 16 | 5.00 | 11 |
| FC100P-4T-22GB | 165.00 | 297.00 | 206.20 | 47.0/45.0 | 30 | 5.50 | 22 |
| FC100P-4T-37G | 225.00 | 360.00 | 231.70 | 77.0/75.0 | 49 | 10.00 | 37 |
| FC100P-4T-55G | 300.00 | 555.00 | 270.00 | 157.0/150.0 | 72 | 36.00 | 55 |
