| Product Introduction |
✓Automatic furnace type, suitable for various high temperature kilns.
✓Suitable for wall thickness around 500mm.
✓Stainless steel probe cover with high corrosion resistance.
✓Special spiral air curtain design prevents dust accumulation.
✓Special air-water cooling for harsh conditions.
✓Sapphire heat resistant lens.
✓PLC program control & 27x optical zoom camera.
|
| Auto-Exit Functions |
⚠Hood temperature above 50°C.
⚠Compressed air pressure below 0.3MPa.
⚠Cooling water flow less than 0.2M³/h.
⚠Power failure or remote exit signal.
|
| Category | Specifications |
|---|---|
| Imaging | Resolution: 1920*1080 | Zoom: 27x Optical | SNR: 56dB |
| Compressed Air | Pressure: 0.3MPa~0.7MPa | Temp: ≤35°C | Flow: 0.3M³/min |
| Cooling Water | Pressure: 0.2~0.5MPa | Temp: ≤35°C | Flow: 0.8M³/h |
| Operating Temp | In Furnace: ≤1800ºC | Auto Device: -20ºC ~ 100ºC |
| Dimensions | Automatic exit device: 1500×400×305mm |
We are a comprehensive high-tech enterprise integrating R&D, production, sales, and installation services. Our core focus is on diversified high-temperature monitoring solutions including high temperature camera systems, portable cameras, endoscopic CCTV systems, and infrared thermal camera systems.
Our products are widely utilized across cement, steel, glass, thermal power, and chemical industries. With multiple invention patents and certifications, we maintain collaborations with leading research institutes to ensure advanced technological exploration.
